NVR-708NS
Details
Affordable, small form factor 8 Channel IP Camera Network recorder for residential and small office use. The 700NS series of IC Realtime NVR's is the entry level for IP Camera storage devices. The 700NS footprint is about the size of a DVD player, while still having room for 2 full size HDDs, and a 8 port integrated POE switch.
Specifications
| System | |
| Main Processor: | Quad-core embedded processor |
| Operating System: | Embedded LINUX |
| Display | |
| Display Interface: | 1 HDMI, 1 VGA |
| Display Resolution: | HDMI: 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720 VGA: 1920 x 1080, 1280 x 1024, 1280 x 720 |
| OSD: | Camera title, Time, Camera lock, Motion detection, Recording |
| HDMI Decoding: | 2ch@4K 30fps 8ch@1080P 30fps |
| Video | |
| Supported Camera Types: | |
| IP Camera Input: | 8 Channel |
| Trigger Events: | Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Video Detection: | Motion Detection, MD Zones: 396 (22 x 18), Video Loss and Tampering |
| Playback: | 1 / 4 / 9 |
| Search Mode: | Time /Date, MD and Exact Search(accurate to second), Smart search |
| Playback Function: | Play, Pause, Stop, Rewind, Fast play, Slow Play,Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode: | USB Device/Network |
| Bit Rate: | 16Kbps ~ 20Mbps Per Channel |
| Audio | |
| Two-way Talk: | 1 Channel Input, 1 Channel Output, RCA |
| Recording | |
| Record Compression: | H.265/ H.264 |
| Record Resolution: | 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P |
| Record Mode: | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Record Interval: | 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Throughput: | 200Mbps |
| Storage | |
| Internal HDD: | 2 SATA III Ports, Up to 8 TB capacity for each HDD |
| HDD Mode: | Single |
| Network | |
| Ethernet: | 1 RJ-45 Port (10/100/1000Mbps) |
| Protocol: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search , Easy4ip |
| Compatibility: | Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more |
| Max. User Access: | 128 Users |
| Smart Phone: | iPhone, iPad, Android |
| Interface | |
| RS232: | N/A |
| RS485: | N/A |
| USB: | 2 ports (1 USB2.0, 1 USB3.0) |
| Electrical | |
| Power Supply: | AC100V ~ 240V, 50 ~ 60 Hz |
| Power Consumption: | NVR: < 9.6W(without HDD) PoE: Max 25.5w for single port, 130w in total |
| Environmental | |
| Operating Conditions: | -10C ~ +55C (+14F ~ +131F), 86 ~ 106kpa |
| Storage Conditions: | -20C ~ +70C (-4F ~ +158F), 0 ~ 90% RH |
| Construction | |
| Dimensions: | 1U, 375mm x 327.5mm x 53mm (14.8" x 12.9" x2.1") |
