IC Realtime’s new NDAA-compliant IPVMX-E40F-IRW1 brings IC Realtime’s famous AI-enhanced detection, image, and stream management capabilities to our most popular camera format. Eyeball domes are “jack of all trades” POE cameras. They combine the tough IP67 weather rating of a dome camera with the mounting & image-aiming efficiency of a bullet camera. With 3 video streams and output settings from 4MP down to CIF, this versatile camera is ready for even the most challenging installations. And it’s HTML5 and OnVif compatible for maximum flexibility.

IPVMX-E40F-IRW1 is designed primarily as a "perfect eyeball” to dependably stream video for VMS systems. It works perfectly with systems like those from IC Realtime’s new partner IPConfigure. But those same specs also make it an ideal choice for any camera system. It’s equipped with a super-sharp 2.8mm glass lens with a 103° x 55° field of view. Behind that lens is a 4MP QHD progressive scan CMOS image sensor with an ultra-low 0.005 lux light sensitivity and 120dB of dynamic range. This chipset maximizes details and instantly adjusts for any lighting conditions.

In total darkness, the IPVMX-E40F-IRW1 uses its dual IR LED illuminators. They reach out 98 feet to invisibly light up the night for ultra-sharp grayscale images. The camera also features a built-in audio mic. It picks up camera-area sound and encodes it with the video stream. Recording sound along with the full motion video provides total situational awareness. Time-stamped video & audio together give context to the recorded video. This results in convincing evidence clips and effective live monitoring.

IC Realtime has continuously AI-enhanced its video gear through multiple product generations. The new IPVMX-E40F-IRW1 benefits from this extensive experience. It employs our latest advanced algorithms and deep-learning processes in both detection and image/stream management. It reduces the pixel count needed for detection so accuracy and reliability are also vastly enhanced. Camera-based Perimeter Protection, iVS, and Tripwire functions are all rendered more responsive & accurate, with an over 90% reduction in false alarms. It can even be used with IC Realtime’s latest AI-NVRs for Intelligent Search.

The sealed “cam ball” of the IPVMX-E40F-IRW1 means it’s both IP67 water resistant and can handle temperatures from -40°F to +140°F. The camera uses less than 8 watts of POE power or can be locally powered by 12VDC where POE isn’t available. Plus, It has a wide power tolerance of ±30% for increased dependability. To adapt it to any installation environment, indoors or out, there is a wide range of custom-fit mounting options available from IC Realtime. And for local “edge” recording, there’s even an mSD slot for cards up to 256Mb built in.

IC Realtime’s camera pros have made eyeball dome cameras their “go-to” camera choice for years, And for good reason. This flexible design fits almost any camera system requirement, is easy to install, and has outstanding specs & reliability. With IC Realtime’s industry-leading 10-year Limited Warranty, the NDAA-certified IPVMX-E40F-IRW1 might just be the most ideal camera choice we’ve ever offered.
