ICR-D4005-IR

(0) No Reviews yet

4MP IP Indoor/Outdoor Small Size Eyeball Dome. Fixed 2.8mm Lens (106°). 90 Feet Smart IR. POE Capable.


SKU: ICR-D4005-IR
ITEM WEIGHT: 2
4MP IP Indoor/Outdoor Small Size Eyeball Dome Fixed 2.8mm Lens (106 AOV) 90 ft Smart IR POE
1/3 CMOS | 4MP | 20fps@4MP
2.8mm | fixed | AoV 123
Max. IR length 98ft | Smart IR
Economic Design | No Audio | No Alarm
IP67 | 12VDC or PoE | Max 4.8W
AGC | DWDR | HLC | BLC | 3DNR

Details

Your favorite 'turret' style camera, now available in the EDGE lineup - the ICR-D4005-IR. The ICR-D4005-IR is a 4MP Day/Night camera with a 2.8mm fixed lens. The camera itself supports H265 and H265+ compression, and True Day/Night viewing at up to 30 meters with 0 light. It's IP67 weather rated as well as PoE. *All Edge series products come with a 3 year limited warranty

Specifications

Camera
Image Sensor: 1/3” 4 Megapixel progressive CMOS
Effective Pixels: 2688(H)x1520(V)
RAM/Rom: 256MB/16MB
Scanning System: Progressive
Electronic Shutter Speed: N/A
Minimum Illumination: 0.09Lux/F2.0( Color,1/3s,30IRE)
0.5Lux/F2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio: More than 50dB
IR Distance: Up to 30m (98ft)
IR On/Off Control: Auto / Manual
IR LEDs: 12
Lens
Lens Type: Fixed
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F2.0
Angle of View: H: 123 V: 101
Optical Zoom: N/A
Focus Control: Fixed
Close Focus Distance: 0.8m(2.63ft)
DORI - Detect: 184ft
DORI - Observe: 73.5ft
DORI - Recognize: 36.7ft
DORI - Identify: 18.4ft
Intelligence
IVS: N/A
Advanced Intelligent Functions: N/A
Video
Compression: H.265/H.264H/MJPEG(Sub Stream)
Streaming Capability: 2 Streams
Resolution: 4M(2688 x 1520) / 3M(2304 x 1296) / 1080P(1920 x 1080) / 720P(1280 x 720) / VGA(640 x 480) / D1(704 x 576 / 704 x 480) / CIF(352 x 288 / 352 x 240)
Frame Rate: Main Stream: 4M(1 ~ 20fps)
Sub Stream: D1(1 ~ 20fps)
Third Stream: N/A
Bit Rate Control: CBR/VBR
Bit Rate: H.265: 12K~ 6144K
H.264: 32K~6144K
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / DWDR
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto / Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS): N/A
Smart IR: N/A
Defog: N/A
Digital Zoom: 16x
Flip: 0 / 90 / 180 / 270
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)
Audio
Compression: N/A
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP / HTTPS / TCP / ARP / RTSP / RTP / RTCP / UDP / SMTP / FTP / DHCP / DNS / DDNS / PPPoE / IPV4/V6 / QoS / UPnP / NTP / Bonjour / IEEE 802.1X / Multicast / ICMP / IGMP / TLS / SSH
Interoperability: ONVIF Profile S&G, API
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users/20 Users
Edge Storage: NAS
Local PC for instant recording
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: SmartICRSS, ICMSS
Smart Phone: IOS, Android
Interface
Video Interface: N/A
RS232: N/A
RS485: N/A
Audio I/O: N/A
Alarm I/O: N/A
Electrical
Power Supply: DC12V, PoE (802.3af)(Class 0)
Power Consumption: <4.8W
Enviromental
Operating Conditions: 30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Operating Humidity: Less than 95% RH
Storage Conditions: 30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Storage Humidity: Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: N/A
Construction
Casing: Metal+Plastic
Dimensions: 109mm×85.5mm (4.29''x3.36'')
Gross Weight: 0.39Kg(0.86lb)
