ICIP-D2732Z

(0) No Reviews yet
SKU: ICIP-D2732Z
ITEM WEIGHT: 5
2MP IP Indoor/Outdoor Mid Size Vandal Dome Varifocal 2.8-12mm Motorized Lens (98 - 30 AOV) 90 ft Smart IR POE
1/2.8 CMOS Starvis | 2MP | 30fps@2MP
2.7mm to 13.5mm | motorized varifocal | AoV 106 to 29
Max. IR length 98ft | Smart IR | 2 IR LEDs
128GB mSD
IP67 | IK10 | 12VDC or PoE | Max. 9W
IVS | AGC | 120dB True WDR | HLC | BLC | 3DNR
Discontinued Item, USE IPFX-D20V-IRW1

Details

The ICIPD2732Z is a 2 megapixel indoor / outdoor camera with a motorized auto focus 2.8mm~12mm varifocal lens. With an IP66 weather rating and 90' IR LEDs, the ICIPD2732Z makes an excellent mid to long range camera.

Specifications

Camera
Image Sensor: 1/2.8 STARVIS CMOS
Effective Pixels: 1920(H) x 1080(V) 2 Megapixels
RAM/Rom: 256MB / 32MB
Scanning System: Progressive
Minimum Illumination: 0.006Lux/F1.4( Color1/3s30IRE) 0.05Lux/F1.4( Color1/30s30IRE) 0Lux/F1.4(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 30m(98ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 2
Lens
Lens Type: Motorized
Mount Type: Board-in
Focal Length: 2.7-13.5mm
Max. Aperture: F1.4
Angle of View: H:106 - 29 degrees V:57 - 17 degrees
Focus Control: Motorized
Close Focus Distance: 200mm (7.87in)
DORI - Detect: 46m (151ft) / 153m (502ft)
DORI - Observe: 18m (59ft) / 61m (200ft)
DORI - Recognize: 9m (30ft) / 30m (98ft)
DORI - Identify: 5m (16ft) / 15m (49ft)
PTZ
Pan/Tilt Range: Pan:0 ~ 355 ;/ Tilt:0 ~ 75 ;/ Rotation:0 ~ 355
Intelligence
Smart Function: Tripwire / Intrusion
Video
Compression: H.265 / H.264H / MJPEG(Sub Stream)
Resolution: 1080P (1920 x 1080) / 1.3M (1280 x 960) / 720P (1280 x 720) / D1 (704 x 576 / 704 x 480) / VGA (640 x 480) / CIF (352 x 288 / 352 x 240)
Frame Rate: Main Stream: 1080P(1 - 25/30fps) Sub Stream: D1(1 - 25/30fps)
Bit Rate: H.265: 12K - 6400Kbps H.264: 32K - 10240Kbps
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / WDR(120dB)
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual
Gain Control: Auto / Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zones Rectangular)
Region of Interest: Off / On (4 Zones)
Smart IR: Supported
Digital Zoom: 16X
Flip: 0 / 90 / 180 / 270
Mirror: Off / On
Privacy Masking: Off / On (4 Area Rectangle)
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP / HTTPs / TCP / ARP / RTSP / RTP / RTCP / UDP / SMTP / FTP / DHCP / DNS / DDNS / PPPoE / IPv4 / IPv6 / QoS / UPnP / NTP / Bonjour / IEEE 802.1x / Multicast / ICMP / IGMP / TLS
Interoperability: ONVIF / PSIA / CGI
Compatability: ONVIF Profile S&G / API
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users
Edge Storage: NAS / Local PC for instant recording / Micro SD Card 128GB
Interface
Video Interface: N/A
Memory Slot: Micro SD Card 128GB
Electrical
Power Supply: DC12V PoE (802.3af)(Class 0)
Power Consumption: < 7W
Enviromental
Operating Conditions: -30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: IK10
Construction
Casing: Metal
Dimensions: 122mm x 88.9mm (4.80in x 3.50in)
Gross Weight: 0.54kg (1.19lb)
