ICIP-D2002-IR-2.8-I

(0) No Reviews yet
SKU: ICIP-D2002-IR-28-I
ITEM WEIGHT: 2
2MP IP Indoor/Outdoor Small Size Vandal Dome Fixed 2.8mm Lens (120 AOV) 60 ft IR POE AI
1/2.8 CMOS Starvis | 2MP | 60fps@2MP
2.8mm | fixed | AoV 110
Max. IR length 66ft | Smart IR | 10 IR LEDs
built-in mic | 128GB mSD
IP67 | 12VDC or PoE | Max. 4.5W
IVS | AGC | 120dB True WDR | HLC | BLC | 3DNR
Discontinued Item, USE IPMX-W20F-IRW1

Details

Bigger is better, at least with image sensors! The ICIP-D2002-IR-2.8-I is a 2MP dome camera featuring our latest generation of 1/2.7'' CMOS sensors. It adopts our popular small style dome housing, and supports IR illumination up to 60'. Due to the larger image sensor, this camera supports a large dynamic range (120 dB), and is considered a 'True' WDR camera. On top of the image sensor sits a fixed, 2.8mm lens which offers up a 120 degree horizontal field of view. This makes the camera well suited for interior and exterior applications on commercial as well as residential installations. The real magic of this camera lies in it's AI (Advanced Intelligence) suite of features, which includes: Tripwire, Intrusion, Scene Change, and Missing Object.

Specifications

Camera
Image Sensor: 1/2.8 2 Megapixel progressive scan STARVIS CMOS
Effective Pixels: 1920(H) x 1080(V)
RAM/Rom: 256MB / 32MB
Scanning System: Progressive
Minimum Illumination: 0.009Lux/F2.0( Color1/3s30IRE) 0.07Lux/2.0( Color1/30s30IRE) 0Lux/F2.0(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 20m (66ft)
IR On/Off Control: Auto/Manual
IR LEDs: 10
Lens
Lens Type: Fixed
Mount Type: Board-in
Focal Length: 2.8 mm
Max. Aperture: F2.0
Angle of View: H: 110 degrees V:58 degrees
Focus Control: Fixed
DORI - Detect: 44m (144ft)
DORI - Observe: 17m (56ft)
DORI - Recognize: 9m (30ft)
DORI - Identify: 4m (13ft)
PTZ
Pan/Tilt Range: Pan:0 ~ 60 ; / Tilt:0 ~ 80 ; / Rotation:0 ~ 360
Intelligence
Smart Function: Tripwire / Intrusion / Abandoned or Missing Object / Face Detection
Video
Compression: H.265+ / H.265 / H.264+ / H.264
Resolution: 1080P (1920 x 1080) / 1.3M (1280 x 960) / 720P (1280 x 720) / D1 (704 x 576 / 704 x 480) / VGA (640 x 480) / CIF (352 x 288 / 352 x 240)
Frame Rate: Main Stream: 1080P(1 - 50/60fps) Sub Stream: D1(1 - 50/60fps) Third Stream: 1080P(1 - 25/30fps)
Bit Rate: H.264: 24 - 9472Kbps H.265: 14 - 5632Kbps
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / WDR(120dB)
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual
Gain Control: Auto / Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zones Rectangular)
Region of Interest: Off / On (4 Zones)
Smart IR: Supported
Digital Zoom: 16x
Flip: 0 / 90 / 180 / 270
Mirror: Off / On
Privacy Masking: Up to 4 areas
Audio
Compression: G.711a / G.711Mu / AAC / G.726
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP / HTTPs / TCP / ARP / RTSP / RTP / UDP / SMTP / FTP / DHCP / DNS / DDNS / PPPOE / IPv4 / IPv6 / QoS / UPnP / NTP / Bonjour / 802.1x / Multicast / ICMP / IGMP / SNMP
Interoperability: ONVIF / PSIA / CGI
Compatability: ONVIF / PSIA / CGI
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users
Edge Storage: NAS / Local PC for instant recording / Micro SD Card 128GB
Interface
Video Interface: N/A
Audio I/O: Built-in Mic
Electrical
Power Supply: DC12V PoE (802.3af)(Class 0)
Power Consumption: < 4.5W
Enviromental
Operating Conditions: -30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: IK10
Construction
Casing: Metal
Dimensions: 106mm x 50.3mm (4.17in x 1.98in)
Gross Weight: 0.44kg (0.97lb)
