AVS-5MD4025-IR
Details
Experience 5 megapixel video with the simplicity of reusing existing coaxial infrastructure! The AVS-5MD4025-IR camera utilizes starlight and HD-AVS technology, suitable to produce a high quality image with rich details even under extreme low-light conditions. The camera also features an audio input capable to provide enhanced supplementary evidence collection. It utilizes a fixed 2.8mm lens and an imager capable of 120dB true WDR and a switchable HD/SD output. IR illumination is available thanks to intelligent IR LEDs capable of illumination at 0 lux up to 98'. Both the high resolution as well as the starlight sensor feature makes this HD-AVS camera an ideal choice for mid to large-size business and projects where both highly reliable surveillance and construction flexibility are needed.
Specifications
| Camera | |
| Image Sensor: | 1/2.8" CMOS |
| Effective Pixels: | 2592(H)×1944(V), 5MP |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.005Lux/F1.6, 30IRE, 0Lux IR on |
| S/N Ratio: | More than 65dB |
| Illumination Distance: | Up to 30m (98ft) |
| Illumination LEDs: | 12 |
| IR Wavelength: | 850 nm |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Fixed lens / Fixed iris |
| Mount Type: | Board-in |
| Focal Length: | 2.8mm |
| Max. Aperture: | F1.6 |
| Angle of View: | H: 98° |
| Focus Control: | Fixed |
| Close Focus Distance: | 800mm(31.5ft) |
| DORI - Detect: | 184ft |
| DORI - Observe: | 72ft |
| DORI - Recognize: | 36ft |
| DORI - Identify: | 20ft |
| Video | |
| Resolution: | 5MP (2592×1944) |
| Frame Rate: | 20fps@5MP, 25/30fps@4MP, 25/30fps@1080P |
| Day/Night: | Auto (ICR) / Manual |
| Backlight Compensation: | Support |
| White Balance: | Auto / Manual |
| Gain Control: | AGC |
| Noise Reduction: | 2D/3D |
| Smart IR: | Support |
| WDR: | 120dB |
| Interface | |
| Video Interface: | 1-channel BNC high definition video output / CVBS video output (DIP switch) |
| Audio I/O: | 1ch input |
| Alarm I/O: | N/A |
| Electrical | |
| Power Supply: | 12V DC ±30% |
| Power Consumption: | Max. 5.3W (12V DC, IR on) |
| Environmental | |
| Operating Conditions: | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH *Startup should be done at above -40°C (-40°F) |
| Ingress Protection: | IP67 |
| Vandal Resistance: | IK10 |
| Construction | |
| Casing: | Aluminum |
| Dimensions: | 109.9mm×81.0mm (4.33"×3.19") |
| Gross Weight: | 0.45kg (0.99lb) |
| Mounting Pan/Tilt/Rotation: | Pan: 0° ~ 355° Tilt: 0° ~ 65° Rotation: 0° ~ 355° |
