32 Channel 2U Pentabrid HD-AVS DVR - Supports up to 4MP AVS / 8MP IP - H.264 - HDMI - Up to 48TB
32 Ch | Up to 4MP HDAVS | Up to 8MP IP Cameras
8 HDDs
2 RJ-45 (10/100/1000Mbps)
4 USB | Alarm 16/6 | 2 HDMI / 1 VGA / 1 TV
128Mbps Total
2U | Rack Mount


The best of all three worlds: analog, AVS and IP. Ideal for installations where the environment is mixed between analog and IP Cameras, or for upgrading existing systems to the next level of resolution. The Tribrid series recorders are capable of recording analog cameras at 960H resolution, HDAVS cameras up to 4MP and IP cameras up to 8MP/4K. Audio is supported on each and every input (both analog, and IP). This series of recorders is dressed up in a full sized 2U DVR capable of housing 8 HDDs internally. The AVR800S series of recorders are available in 4, 8, 16, 24, and 32 channel offerings, enabling it to be deployed into installations of nearly any size. This makes the recorder perfect for applications ranging from small to medium business, residential, or even large scale enterprise applications. Since the AVR800S series of recorders supports analog, HDAVS and IP cameras, it is a good fit for existing installations that want to expand into IP cameras without replacing analog cameras completely. This device utilizes H.265 compression technology, enabling crisp image viewing with the least bandwidth consumption possible. It adopts an embedded system design, as well as a Linux Operating System resulting in high levels of stability, performance, and most importantly: reliability. In addition, this unit is fully operational from both local and remote network locations!


Main Processor: Embedded Processor
Operating System: Embedded LINUX
Display Interface: 2 HDMI ,1 VGA, 1 TV
Display Resolution: HDMI 1:3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720 HDMI 2 / VGA: 1920 x 1080, 1280 x 1024, 1280 x 7201920 x 1080, 1280 x 1024, 1280 x 720
Multi-screen Display: 1/4/8/9/16/25/36
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
IP Camera Input: 32 Channel, each channel up to 8MP
HDAVS input: 32 Channel
Trigger Events: Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 x 18), Video Loss, Tampering and Diagnosis
Bit Rate: 32Kbps ~ 6144Kbps Per Channel
Two-way Talk: 1 Mic In, 1 Mic Out, BNC
Record Compression: H.265+/H.265/H.264+/H.264
Record Resolution: 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
Record Rate: Main stream:the 1st & 2nd channel 5M-N�シ�1~10fps) others 4M-N/1080P(1~15fps); 1080N/720P/960H/D1/CIF (1~25/30fps) Sub stream: D1/CIF(1~15fps)
Record Mode: Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval: 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Smart Phone: iPhone, iPad, Android
