NVR-716N

(0) No Reviews yet
SKU: NVR-716N-WEB
ITEM WEIGHT: 20
16 Channel 2U NVR - Supports 5MP Resolution - 200Mpbs throughput - H.264 - HDMI - up to 48TB
16 Ch | Up to 8MP | 200Mbps Total
8 HDDs
2 RJ-45 (10/100/1000Mbps)
3 USB | Alarm 16/4 | 1 HDMI / 1 VGA
ONVIF 2.4 CGI Conformant
2U | Desktop or Rack Mount

Details

The 700N series is ICRealtime's medium level platform with a 16 channel capability and 200Mbps of recording ability. Strong, silent, and feature rich, the 700N is a full sized (19' wide, 2U high) NVR capable of housing 8 HDDs internally. Powerful and robust processing are at the core of the NVR700N series. Dual Gigabit Network Interface ports enable higher resolutions and faster frame rates for recording, which can also be configured for Fault Tolerance and Load Balancing.

Specifications

System
Main Processor: Quad-core embedded processor
Operating System: Embedded LINUX
Display
Display Interface: 1 HDMI, 1 VGA
Display Resolution: HDMI: 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720 VGA: 1920 x 1080, 1280 x 1024, 1280 x 720
Multi-screen Display: 1/4/8/9/16
OSD: Camera title, Time, Camera lock, Motion detection, Recording
HDMI Decoding: 2ch@4K 30fps 8ch@1080P 30fps
Video
IP Camera Input: 16 Channel
Trigger Events: Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 x 18), Video Loss and Tampering
Playback: 1 / 4 / 9 / 16
Search Mode: Time /Date, MD and Exact Search (accurate to second), Smart search
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Bit Rate: 16Kbps ~ 20Mbps Per Channel
Audio
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Recording
Record Compression: H.265/ H.264
Record Resolution: 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P
Record Rate: 200Mbps
Record Mode: Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
Record Interval: 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Storage
Internal HDD: 8 SATA III Ports, Up to 6 TB capacity for each HDD
HDD Mode: Single
Network
Ethernet: 2 RJ-45 Ports
Protocol: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search , Easy4ip
Compatability: Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
Max. User Access: 128 Users
Smart Phone: iPhone, iPad, Android
Interface
RS232: 1 Port, for PC Communication and Keyboard
RS485: 1 Port, for PTZ Control
USB: 3 ports(2 USB2.0, 1 USB3.0)
Electrical
Power Supply: AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption: < 12W(without HDD)
Enviromental
Operating Conditions: -10C ~ +55C (+14F ~ +131F), 86 ~ 106kpa
Storage Conditions: -20C ~ +70C (-4F ~ +158F), 0 ~ 90% RH
Construction
Dimensions: 2U, 440mm x 450.1mm x 95mm (17.3" x 17.7" x3.7")
