NVR-6064K

(0) No Reviews yet
SKU: NVR-6064K-WEB
ITEM WEIGHT: 20
64 Channel 2U 4K NVR. Up to 12MP IP Camera Support. 256Mbps Camera Throughput. Up to 64TB.
64 Ch | Up to 12MP | 384Mbps Total
8 HDDs | 0/1/5/10
2 RJ-45 (10/100/1000Mbps)
4 USB | Alarm 16/8 | 2 HDMI / 1 VGA
ONVIF 2.4 CGI Conformant
2U | Desktop or Rack Mount

Details

The NVR-6064K is designed for large projects that require super high definition 4K video for both recording and display. With 64 channels of video and an extreme total data bandwidth of 256Mbps this recorder delivers video in crystal 4K clarity. With these new 4K recording NVRs and with IC Realtime 3MP, 4MP, 5MP, or 12MP cameras, amazing detail capture is possible. Several levels of zoom allow users to grab every detail and enlarge it with almost no loss of clarity and legibility. Whether the surveillance system is for a large auditorium, stadium, or car dealership, this 4K recorder delivers high performance video for facial and product identification, employee management or vandalism prevention. Two independent Ethernet ports allow for gigabit fast data streams, which prevents video loss. 8 SATA III harddrive controllers can store up to 64TB of video, plenty of storage capacity for large facilities. The NVR-6064K includes dual HDMI ports, RAID HD management, event alarm snapshots and true 4K video search and display. Channel Bandwidth Breakdown Examples:
21 * 12 MP Cameras at 12Mbps
21 * 6 MP Cameras at 12Mbps
32 * 3 MP Cameras at 8Mbps
32 * 2 MP Cameras at 8Mbps
42 * 12 MP Cameras at 6Mbps
42 * 6 MP Cameras at 6Mbps
64 * 3 MP Cameras at 4Mbps
64 * 2 MP Cameras at 4Mbps
64 * 1.3 MP Cameras at 4Mbps

Specifications

System
Main Processor: Intel Quad-core Processor
Operating System: Embedded LINUX
Display
Display Interface: 2 HDMI (up to 3840 x 2160 , Different Source), 1 VGA
Display Resolution: "3840 x 2160 , 1920 x 1080 , 1280 x 1024, 1280 x 720 , 1024 x 768"
Multi-screen Display: 1st Screen: 1/4/8/9/16/25/36, 2nd Screen: 1/4/8/9/16
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video
IP Camera Input: 64 Channel
Trigger Events: Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 x 18), Video Loss and Tampering
Playback: 128 Mbps in Raid 5 Mode; 64 Mbps in single HDD Mode
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network/eSATA Device
Bit Rate: 16Kbps ~ 20Mbps Per Channel
Audio
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Recording
Record Compression: H.265/H.264/MJPEG
Record Resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc.
Record Rate: 384Mbps
Record Mode: Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop
Record Interval: 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Storage
Internal HDD: 8 SATA III Ports, Up to 8 TB capacity for each HDD
HDD Mode: Single, Raid 0/1/5/10(Enterprise-level HDDs are recommended), Support Global HDD Hot-spare
eSATA: 1 eSATA Port (Please contact technical engineer to confirm the compatible device)
Network
Ethernet: 2 RJ-45 Ports (10/100/1000Mbps)
Protocol: HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search
Compatability: IC Realtime, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Max. User Access: 128 Users
Smart Phone: iPhone, iPad, Android
Interface
RS232: 1 Port, for PC Communication and Keyboard
RS485: 1 Port, for PTZ Control
USB: 4 USB Ports (2 USB 2.0 , 2 USB 3.0 )
Electrical
Power Supply: AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption: <20W (Without HDD)
Enviromental
Operating Conditions: -10C ~ +55C (+14F ~ +131F), 86 ~ 106kpa
Storage Conditions: -20C ~ +70C (-4F ~ +158F), 0 ~ 90% RH
Construction
Installation: Rack-mounted
Dimensions: 2U, 440mm x 451.08mm x 94.85mm (17.3" x 17.8" x 3.7")
