NVR-208NS

(0) No Reviews yet
SKU: NVR-208NS-WEB
ITEM WEIGHT: 20
8 Channel 1U NVR - Integrated 8 Port POE Switch - Supports 8MP Resolution - 80Mbps throughput - H.264 - HDMI - up to 6TB
8 Ch | Up to 8MP | 80Mbps Total
1 HDD
8 PoE (IEEE802.3af/at) 1 RJ-45 (10/100/1000Mbps)
2 USB | 1 HDMI / 1 VGA
ONVIF 2.4 CGI Conformant
Compact 1U | Desktop or Rack Shelf

Details

Your favorite embedded NVR, now available in the EDGE lineup - the NVR-208NSS The NVR-208NS is an 8 channel Lite 4K NVR with integrated PoE, H.265/H.264 Decoding and plug-and-play IP Camera connectivity. It can decode up to 1 channel at 8MP (4 channel at 1080P) and supports a max of 80Mbps incoming bandwidth. *All Edge series products come with a 3 year limited warranty

Specifications

System
Main Processor: Dual-core embedded processor
Operating System: Embedded LINUX
Display
Display Interface: 1 HDMI, 1 VGA
Display Resolution: HDMI: 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, VGA: 1920 x 1080, 1280 x 1024, 1280 x 720
Multi-screen Display: 1/4/8/9
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
HDMI Decoding: 1ch@8MP 30fps, 4ch@1080P 30fps
Video
IP Camera Input: 8 Channel
Trigger Events: Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 x 18), and Tampering
Playback: 1/4
Search Mode: Time /Date, MD and Exact Search (accurate to second), Smart search
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Bit Rate: 16Kbps ~ 20Mbps Per Channel
Audio
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Recording
Record Compression: H.265/H.264
Record Resolution: 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P
Record Rate: 80Mbps
Record Mode: Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop
Record Interval: 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Storage
Internal HDD: 1 SATA III Port, up to 6TB capacity for each HDD
HDD Mode: Single
eSATA: N/A
Network
Ethernet: 1 RJ-45 port (10/100/1000Mbps)
Protocol: HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support IC Realtime IP camera, DVR, NVS and etc.), Easy4ip
Compatability: Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interface
RS232: N/A
RS485: N/A
USB: 2 ports (1 Rear USB2.0, 1 Front USB2.0)
Electrical
Power Supply: Single, DC48V/2A
Power Consumption: NVR: <5.8W (without HDD), PoE: Max 25.5w for single port, 80w in total
Enviromental
Operating Conditions: -10C ~ +55C (+14F ~ +131F), 86 ~ 106kpa
Storage Conditions: -20C ~ +70C (-4F ~ +158F), 0 ~ 90% RH
Construction
Dimensions: Compact 1U, 260mm x 224.9mm x 47.6mm (10.2" x 8.9" x 1.9")
