MNVR-EL04
Details
In-Dash Security
IC Realtime’s MNVR-EL04 is a 4 channel, 4K Network Video Recorder purpose built for mobile/ vehicle applications. This tough, shockproof, compact NVR features 4 built-in PoE ports supporting cameras up to 4K in resolution. Other features include an anti-vibration storage enclosure for up to 1TB HDD, H.265 support, 6/1 alarm input/ output as well as ONVIF 2.3 compliant for use with numerous third-party IP cameras.
Mobile Surveillance with Brains
Seamlessly connect from our IC Now desktop or IC VIew+ Mobile app while the MNVR-equipped vehicle is on the road using a 4G mobile (Verizon only) data plan. The MNVR also features WiFi connections with GPS capability for remote management and surveillance options. IC Realtime cameras with Face Detection and Recognition are supported by the NVR as well, expanding the possibilities for mobile surveillance.
Specifications
| System | |
| Main Processor: | Dual-core embedded processor |
| Operating System: | Embedded LINUX |
| Display | |
| Display Interface: | 1 VGA, 1HDMI |
| Display Resolution: | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Display Split: | 1/4 |
| Intelligence | |
| Advanced Intelligent Functions: | (Supported by Camera) Face Detection, Face Recognition |
| Video | |
| Supported Camera Types: | IP |
| IP Camera Input: | 4 |
| Trigger Events: | Recording, PTZ, Tour, Alarm out, Email, FTP, Snapshot, Buzzer & Screen tips |
| Video Detection: | Motion Detection, MD Zones: 396(22×18), Video Loss & Blank Camera Channel |
| Playback: | 1/4 |
| Search Mode: | Time/Date, Alarm, Motion Detection & Exact search (accurate to second), Smart search |
| Playback Function: | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Bit Rate: | 48~8192Kb/s Per Channel |
| Audio | |
| Compression: | G.711/PCM |
| Two-way Talk: | Supported |
| Recording | |
| Record Compression: | H.265/H.264 |
| Record Resolution: | 4K/ 5MP/ 3MP/ 1080P(1920×1080)/ 720P(1280×720)/ D1(704×576/704×480)/ HD1(352×576/352×480)/ 2CIF(704×288/704×240) CIF(352×288/352×240)/ QCIF(176×144/176×120) |
| Record Bit Rate: | 48~8192Kb/s Per Channel |
| Incoming Bandwith: | 200Mbps |
| Throughput: | 200Mbps |
| Storage | |
| Internal HDD: | 1 SATA Port, Up to 1 TB capacity |
| Network | |
| Ethernet: | 1 RJ-45 Port (10/100/1000 Mbps) |
| Protocol: | TCP/IP, UDP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Email, Alarm Server |
| Wifi: | Supported |
| Compatibility: | ONVIF 2.3 |
| Max. User Access: | 128 users |
| Web Viewer: | IE, Chrome, Safari, Firefox, Edge |
| Management Software: | IC Now, DSS |
| Smart Phone: | iOS, Android (IC View+) |
| GPS: | Supported |
| PoE: | 4 |
| Interface | |
| RS232: | 2 Ports, for PC Communication and Keyboard |
| RS485: | 1 Port, for PTZ Control |
| USB: | 2 Ports , USB 2.0 |
| Audio I/O: | 1 Channel Mic in, 1 Channel Mic out |
| Memory Slot: | 1 SD Slot |
| Electrical | |
| Power Supply: | DC 6V~36V |
| Power Consumption: | <15W (without HDD) |
| Environmental | |
| Operating Conditions: | -31°F (-35°C) (heater optional)~+140°F (60°C) / 10%~95%RH / 86~106kpa |
| Construction | |
| Installation: | Mobile |
| Dimensions: | 7.48" x 8.26" x 2.36" (190mm×210mm×60mm ) |
