IPVFX-B40V-IRW1
Details
Bullet-style security cameras are the stalwart veterans of the video security industry. Their familiar tubular design is associated with tight security and situational awareness wherever they appear. IC Realtime’s new IPVFX-B40V-IRW1 is an advanced 4MP QHD Starlight POE camera equipped with a power varifocal lens that enables users to dial in the perfect field of vision shot no matter where the camera is positioned.
4MP QHD POWER ZOOM SHARP + STARLIGHT SENSITIVE
IPVFX-B40V-IRW1 is equipped with an autofocus power zoom 2.7mm medium wide angle to 13.5mm lens system. This dramatically eases camera positioning restrictions. A perfect Field of View can be set no matter where the camera needs to be mounted. This lens system sharply focuses on the camera’s Starlight video sensor. This chip is the latest design. Its density exceeds the previous pixel density standard of 1080P HD, with a 2688 x 1520 Quad HD (QHD) pixel density rating. Every pixel is also exquisitely Starlight sensitive, capable of holding image color down to 0.005 lux before switching to grayscale. It also incorporates our latest and most detail-revealing 120dB of Wide Dynamic Range right on the chip. All this means the sensor’s detailed output is optimized at the point of detection, even before IC Realtime’s legendary image processing gets ahold of it.
WEATHERPROOF + FLEXIBLE MOUNTING BASE
The IPVFX-B40V-IRW1 comes with a weather-hardened IP67 weather rating. Its full-metal case & integrated mount & base system are suitable for any environment. It has a wide operating temperature range of -22F to +140F so it works indoors & outdoors, in every season. For easy installation, bullet cameras remain the top professional choice. No other camera design beats the mounting & image-aiming flexibility of a bullet camera. And IC Realtime has perfectly fit & color-matched mounting options in stock to meet any site requirements.
COMMERCIAL-GRADE PLUS AUDIO & ALARM I/O
The mark of a professional-grade security camera is its ability to interconnect with systems like access control, vehicle gates, and door intercom systems. IPVFX-B40V-IRW1 has both 2-way audio I/O and alarm I/O leads so it can interface as a component of these larger systems. Audio and alarm indications are encoded and streamed with the camera’s video.
IC Realtime’s bullet-style cameras offer maximum base positioning options and enough internal capacity for both advanced zoom lenses and sophisticated image processing electronics. Their lens distance from their flexible integrated mounting arms lets them twist around to work where other cameras won’t. And their accessible base makes them our most easily installed & aimed camera options. As one of our newest cameras, IC Realtime’s new IPVFX-B40V-IRW1 is a cost-efficient way to bring that flexibility and the latest AI skills and 4MP QHD video quality to your next VMS, cloud, or NVR-based camera system installation.
Specifications
| Camera | |
| Image Sensor: | 1/3” 4 Megapixel progressive CMOS |
| Effective Pixels: | 2688 (H) ×1520 (V) |
| RAM/Rom: | 128 MB/512MB |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.005 Lux@F1.5 |
| Illumination Distance: | 60 m (197 ft) |
| Illumination On/Off Control: | Auto/Manual |
| Illumination LEDs: | 4 |
| IR Wavelength: | 850 nm |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Motorized vari-focal |
| Mount Type: | φ14 |
| Focal Length: | 2.7 mm–13.5 mm |
| Max. Aperture: | F1.5 |
| Angle of View: | Horizontal: 104°–27° Vertical: 55° –15° Diagonal: 124° –31° |
| Close Focus Distance: | 0.8 m (2.6 ft) |
| DORI - Detect: | 64.0 m (210.0ft)/ 222.0 m (728.3 ft) |
| DORI - Observe: | 25.6 m (84.0 ft)/ 88.8m(291.3 ft) |
| DORI - Recognize: | 12.8 m (42.0 ft)/ 44.4 m(145.7 ft) |
| DORI - Identify: | 6.4 m(21.0 ft)/ 22.2 m(72.8 ft) |
| Video | |
| Compression: | H.265; H.264; H.264H; H.264B; MJPEG |
| Streaming Capability: | 3 streams |
| Resolution: | 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate: | Main stream (2688 × 1520@1–25/30 fps) Sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps) Third stream (1280 × 720@1–25/30 fps |
| Bit Rate: | H.264: 3 Kbps–8192 Kbps H.265: 3 Kbps–8192 Kbps |
| Day/Night: | Auto(ICR)/Color/B/W |
| Backlight Compensation: | Yes |
| White Balance: | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control: | Auto/Manual |
| Noise Reduction: | 3D DNR |
| Motion Detection: | OFF/ON (4 areas, rectangular) |
| Region of Interest: | Yes (4 areas) |
| Smart IR: | Yes |
| Flip: | 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.) |
| Privacy Masking: | 4 areas |
| WDR: | 120 dB |
| Audio | |
| Compression: | G.711a; G.711Mu; G726; AAC |
| Network | |
| Ethernet: | RJ-45 (10/100 Base-T) |
| Protocol: | IPv4; IPv6; HTTP; HTTPS;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Interoperability: | ONVIF(Profile S/Profile G) |
| Streaming Method: | Unicast / Multicast |
| Max. User Access: | 20 (Total bandwidth: 64 M) |
| Edge Storage: | FTP; SFTP; Micro SD Card (support max. 256 G); NAS |
| Web Viewer: | IE: IE8, IE9, IE11 Chrome Firefox |
| Interface | |
| Audio I/O: | 1-channe Input(RCA port) 1-channel Output(RCA port) |
| Alarm I/O: | 1 channel in: 5mA 3V–5V DC 1 channel out: 300mA 12V DC |
| Memory Slot: | Micro SD Card (support max. 256 GB) |
| Electrical | |
| Power Supply: | 12V DC/PoE (802.3af) |
| Power Consumption: | <9.8W |
| Environmental | |
| Operating Conditions: | -22°F to +140°F (-30°C to +60°C)/less than≤95% |
| Storage Conditions: | -40°F to +140°F (-40°C to +60°C) |
| Ingress Protection: | IP67 |
| Construction | |
| Casing: | Metal |
| Dimensions: | 9.6" × 3.1" × 3.0" (244.1 mm × 79.0 mm × 75.9 mm) |
| Gross Weight: | 2.4lb (1090 g) |
| Mounting Pan/Tilt/Rotation: | Horizontal: 0°–360°; vertical: 0°–90°; rotation: 0°–360° |
