IPND-P2040X-IRW1
Details
IPND-P2040X-IRW1 — 2MP NDAA & TAA-Compliant 40× Optical Zoom IR PTZ Camera
2MP NDAA-compliant and TAA-compliant PTZ camera featuring 40× optical zoom, Smart IR illumination up to 250 meters, AI-powered object analytics, WDR Pro imaging, and enterprise-grade cybersecurity for long-range perimeter surveillance.
Overview
The IPND-P2040X-IRW1 is a professional PTZ camera purpose-built for large-scale surveillance where operators need to actively monitor expansive areas from a single camera. Featuring 40× optical zoom, high-speed pan and tilt operation, and Smart IR illumination reaching up to 250 meters, it supports long-range visibility across large campuses, utility sites, transportation facilities, airports, ports, and critical infrastructure.
Unlike fixed cameras, the IPND-P2040X-IRW1 allows security personnel to reposition the camera, zoom into distant activity, and follow subjects across wide areas. Built-in AI analytics generate intelligent metadata that supports Deep Search AI investigations within the IC Secure platform.
As part of the complete IC Secure ecosystem, the PTZ integrates with IC Secure recording servers and enterprise video management software, providing centralized management, enterprise recording, and simplified long-term ownership.
Key Benefits
- 40× Optical Zoom — Capture distant activity using a 4.25–170 mm motorized autofocus optical zoom lens.
- Long-Range Smart IR — Eight Smart IR LEDs provide nighttime illumination up to 250 meters for perimeter and low-light surveillance.
- High-Speed PTZ Control — 360° endless pan, -20° to +90° tilt, auto flip, and pan/tilt speeds up to 450° per second support active monitoring of wide areas.
- AI Analytics at the Camera — Supports people and vehicle detection, face detection, intrusion detection, line crossing, loitering, unattended object detection, missing object detection, Advanced Smart Tracking, object attributes, and best-shot extraction.
- Enterprise Cybersecurity — Includes Secure Boot, signed firmware, HTTPS, IEEE 802.1X authentication, TLS 1.2/1.3, user account management, audit logs, and enterprise network security features.
- Compliance by Design — NDAA-compliant, TAA-compliant, and UL Listed for projects requiring trusted surveillance equipment.
Quick Specs
Built for Compliance-Driven Projects
Every IC Secure camera is NDAA-compliant, TAA-compliant, and UL Listed, making the platform an excellent choice for government, education, healthcare, critical infrastructure, transportation, utilities, and enterprise surveillance deployments where trusted products and long-term reliability are essential.
Applications
- Critical infrastructure
- Utility substations
- Airports
- Ports and maritime facilities
- Transportation hubs
- Large enterprise campuses
- Perimeter security
- Parking facilities
- Correctional facilities
- Industrial sites
Part of the IC Secure Platform
The IPND-P2040X-IRW1 is designed to work seamlessly with IC Secure recording servers and professional video management software. Together, they create one complete surveillance ecosystem featuring centralized management, Deep Search AI, intelligent video analytics, enterprise recording, and simplified ownership with no separate software licensing to purchase or manage.
FAQ
What is a PTZ security camera?
A PTZ camera allows operators to remotely pan, tilt, and zoom the camera to monitor large areas from a single device. PTZ cameras are commonly used for active surveillance, perimeter protection, and long-range monitoring.
What does 40× optical zoom mean?
A 40× optical zoom lens magnifies distant subjects using the camera's optics rather than digital enlargement. This helps preserve image detail when monitoring gates, fence lines, parking lots, roadways, utility sites, or other large outdoor areas.
When should I choose a PTZ camera instead of a fixed camera?
PTZ cameras are ideal when operators need to actively monitor large areas, investigate events in real time, or track people and vehicles across expansive properties. Fixed cameras are better suited for continuous monitoring of specific locations.
How far can the camera see at night?
The IPND-P2040X-IRW1 features Smart IR illumination with a maximum range of 250 meters, providing nighttime visibility for long-range surveillance applications.
Can the camera automatically track people or vehicles?
Yes. The camera supports Advanced Smart Tracking, allowing it to follow detected objects while generating intelligent metadata that can support investigation workflows through the IC Secure platform.
What is Deep Search AI?
Deep Search AI is an investigation capability included with the IC Secure platform that uses searchable AI metadata generated by supported IC Secure cameras to quickly locate people, vehicles, faces, and important events within recorded video.
Can IC Secure PTZ cameras work with ONVIF systems?
Yes. The IPND-P2040X-IRW1 supports ONVIF Profiles G, S, and T for interoperability with compatible video management systems. It is also designed to integrate with IC Secure recording servers and professional video management software as part of the complete IC Secure platform.
Do IC Secure cameras require recurring software licenses?
When paired with an IC Secure recording server, enterprise video management software is included for the server's advertised camera capacity. There are no separate recurring VMS software licenses to purchase or manage.
Where are PTZ cameras commonly deployed?
PTZ cameras are commonly installed at airports, utility sites, transportation hubs, ports, industrial facilities, correctional facilities, enterprise campuses, parking lots, and other locations where long-range visibility and active monitoring are required.
Why choose the complete IC Secure platform?
IC Secure combines NDAA-compliant, TAA-compliant, and UL Listed cameras, enterprise recording servers, and professional video management software into one integrated ecosystem. Together they provide centralized management, Deep Search AI, intelligent video analytics, enterprise recording, and simplified long-term ownership through a unified surveillance platform.
Specifications
| Camera | |
| Image Sensor: | 1/2.8" Progressive CMOS |
| Effective Pixels: | 1920 (H) × 1080 (V) |
| RAM/Rom: | 8GB/ 2GB |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.004 lux @ F1.6 (Color) <0.005 lux @ F1.6 (B/W) 0 lux with IR illumination on |
| S/N Ratio: | 60 dB |
| Illumination Distance: | Up to 820 ft (250 m) |
| Illumination On/Off Control: | Auto/ Manual |
| Illumination LEDs: | 8 |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Motorized Vari-focal |
| Focal Length: | 4.25 ~ 170mm |
| Max. Aperture: | F1.6 ~ F74.95 |
| Angle of View: | Horizontal: 65.7° ~ 1.9°; Vertical: 39.4° ~ 1.1°; Diagonal: 73.0° ~ 2.1° |
| Focus Control: | Auto / Manual |
| DORI - Detect: | Wide: 61.1 m (200.4 ft) Tele: 2239 m (7345.7 ft) |
| DORI - Observe: | Wide: 24.2 m (79.5 ft) Tele: 888.5 m (2914.9 ft) |
| DORI - Recognize: | Wide: 12.2 m (40 ft) Tele: 447.8 m (1469.1 ft) |
| DORI - Identify: | Wide: 6.1 m (20 ft) Tele: 223.9 m (734.5 ft) |
| PTZ | |
| Pan/Tilt Range: | Pan: 360° / Tilt: -20° to +90° |
| Intelligence | |
| IVS: | Line crossing; Intrusion, Unattended object; Missing object, Loitering detection, Face detection |
| Advanced Intelligent Functions: | Object Detection: People, Vehicle (4-wheeled, 2-wheeled), Human / Vehicle Best shot, Path Extraction Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color) |
| Video | |
| Compression: | H265, H264, MJPEG |
| Resolution: | 1920x1080, 1600x904, 1360x768, 1280x720, 640x360 |
| Frame Rate: | 30 fps @ 1920x1080 (WDR on) 60 fps @ 1920x1080 (WDR off) |
| Bit Rate Control: | Fixed Quality / Constrained |
| Bit Rate: | H.264: 20 Kbps–80 Mbps H.265: 20 Kbps–80 Mbps |
| Day/Night: | Auto(ICR) / Color / B/W / Schedule |
| Backlight Compensation: | BLC / HLC / WDR |
| White Balance: | Default (Auto)/Fixed/Manual |
| Gain Control: | Auto / Manual |
| Noise Reduction: | 3DNR |
| Motion Detection: | Off / On (5 Area) |
| Flip: | Off / On |
| Mirror: | Off / On |
| Privacy Masking: | Off / On (24 Area) |
| WDR: | WDR Pro |
| Audio | |
| Compression: | G.711, G.726, MPEG-2 AAC-LC |
| Network | |
| Ethernet: | 10Base-T/100Base-TX Ethernet (RJ-45) |
| Protocol: | 802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, , NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP |
| Interoperability: | ONVIF (Profile S/Profile G/Profile T) |
| Max. User Access: | Live streaming for up to 10 users / devices |
| Management Software: | IC Secure |
| Smart Phone: | IOS, Android |
| Interface | |
| Factory Reset: | Supported |
| Memory Slot: | Micro SD Card (support max. 1TB) |
| Electrical | |
| Power Supply: | 24VAC, 48VDC, IEEE 802.3bt Class 6 PoE |
| Power Consumption: | IR ON: 51W/45W Heater and fan on/off IR OFF: 26W/20W Heater and fan on/off |
| Environmental | |
| Operating Conditions: | Starting Temperature: -40°C ~ 55°C (-40°F ~ 131°F) Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) (IR on) |
| Operating Humidity: | 98% RH (non-condensing) |
| Ingress Protection: | IP66 |
| Vandal Resistance: | IK10 |
| Construction | |
| Dimensions: | Ø 256mm x 336 mm (Ø 10.08" × 13.23") |
