IPND-B80V-IRW1
Details
IPND-B80V-IRW1 — 8MP NDAA & TAA-Compliant Varifocal IR Bullet Camera
8MP NDAA-compliant and TAA-compliant bullet camera featuring a motorized autofocus varifocal lens, Smart IR illumination, AI-powered video analytics, WDR Pro, and enterprise-grade cybersecurity for perimeter and long-range surveillance deployments.
Overview
The IPND-B80V-IRW1 is a professional 8MP IR bullet camera designed for perimeter security, utilities, parking lots, entrances, commercial properties, and other environments where visible deterrence, high-resolution imaging, and reliable outdoor performance matter.
With a 4.3–9.8 mm motorized autofocus varifocal lens, the camera allows installers to remotely adjust zoom and focus to optimize coverage after installation. Its bullet form factor makes it especially useful for exterior walls, fence lines, gates, loading areas, parking lots, and other directional surveillance applications.
As part of the IC Secure platform, the IPND-B80V-IRW1 combines Smart IR illumination, WDR Pro imaging, on-camera AI analytics, and enterprise cybersecurity into one professional surveillance solution that integrates with IC Secure recording servers and video management software.
Key Benefits
- Perimeter-Focused Bullet Design — Directional bullet form factor is well suited for exterior walls, gates, fence lines, parking lots, loading docks, and perimeter applications.
- 8MP Ultra HD Imaging — Captures detailed video at up to 3840 × 2160 resolution for live monitoring, evidence collection, and forensic investigations.
- Motorized Autofocus Varifocal Lens — 4.3–9.8 mm motorized lens supports remote zoom and focus adjustment, allowing installers to optimize coverage after installation.
- Smart IR Night Vision — Four built-in IR LEDs provide illumination up to 40 meters for dependable nighttime surveillance.
- AI Analytics at the Camera — Supports people and vehicle detection, face detection, intrusion detection, line crossing, loitering, unattended object detection, missing object detection, and Advanced Smart Tracking while generating intelligent metadata for investigation workflows.
- WDR Pro Performance — Helps maintain image detail in scenes containing both bright and dark areas for improved visibility in challenging lighting conditions.
- Enterprise Cybersecurity — Includes Secure Boot, signed firmware, HTTPS, IEEE 802.1X authentication, TLS 1.2/1.3, a built-in FIPS 140-2 Level 2 certified Trusted Platform Module (TPM), user account management, and additional network security protections.
- Compliance by Design — NDAA-compliant and TAA-compliant architecture designed for government, education, utilities, transportation, commercial, and enterprise environments.
Quick Specs
Built for Compliance-Driven Projects
Every IC Secure camera is NDAA-compliant, TAA-compliant, and UL Listed, making the platform an excellent choice for government, education, healthcare, critical infrastructure, transportation, commercial, and enterprise surveillance deployments where trusted products and long-term reliability are essential.
Applications
- Perimeter security
- Utilities
- Parking lots
- Loading docks
- Building exteriors
- Vehicle entrances
- Fence lines
- Commercial properties
- Transportation facilities
- Enterprise campuses
Part of the IC Secure Platform
The IPND-B80V-IRW1 is designed to work with IC Secure enterprise recording servers and professional video management software. Together, they create one complete surveillance ecosystem featuring centralized management, Deep Search AI, intelligent video analytics, enterprise recording, and simplified ownership with no separate software licensing to purchase or manage.
FAQ
What is a bullet security camera used for?
A bullet security camera is commonly used for directional surveillance in outdoor or perimeter environments. Its visible form factor makes it well suited for monitoring gates, fence lines, parking lots, loading docks, building exteriors, and other areas where focused coverage is needed.
When should I choose a bullet camera instead of a dome camera?
A bullet camera is often preferred for exterior and perimeter applications where the camera should be visible and aimed in a specific direction. Dome cameras are often used in public-facing areas where a lower-profile, vandal-resistant design is preferred.
Is the IPND-B80V-IRW1 suitable for outdoor installations?
Yes. The IPND-B80V-IRW1 features an IP67 weather-resistant rating and an IK10 impact-resistant rating, making it suitable for demanding outdoor surveillance deployments.
Can the viewing angle be adjusted after installation?
Yes. The IPND-B80V-IRW1 features a 4.3–9.8 mm motorized autofocus varifocal lens with remote zoom and focus controls, allowing installers to fine-tune scene coverage after installation.
Why use an 8MP bullet camera for perimeter security?
An 8MP bullet camera provides high-resolution detail for monitoring exterior areas, entrances, parking lots, and perimeter approaches. The added resolution helps operators review recorded video with more detail compared with lower-resolution cameras captured under similar conditions.
How do AI analytics improve video surveillance?
Supported IC Secure cameras analyze video at the camera to detect people, vehicles, faces, and defined events while generating intelligent metadata. This metadata supports event detection and more efficient investigation workflows within the IC Secure platform.
What is Deep Search AI?
Deep Search AI is an investigation capability included with the IC Secure platform that uses searchable video metadata to help operators quickly locate relevant people, vehicles, and events within recorded video.
Can IC Secure cameras work with ONVIF systems?
Yes. The IPND-B80V-IRW1 supports ONVIF Profiles G, S, T, and M for interoperability with compatible video management systems. IC Secure cameras are also designed to integrate with IC Secure recording servers and professional video management software as part of the complete IC Secure platform.
Do IC Secure cameras require recurring software licenses?
When paired with an IC Secure recording server, enterprise video management software is included for the server's advertised camera capacity. There are no separate recurring VMS software licenses to purchase or manage.
Why choose the complete IC Secure platform?
IC Secure combines NDAA-compliant, TAA-compliant, and UL Listed cameras, enterprise recording servers, and professional video management software into one integrated ecosystem. The platform provides centralized management, intelligent video analytics, AI-powered investigation capabilities, enterprise recording infrastructure, and a consistent software experience across every server model while eliminating separate software licensing.
Specifications
| Camera | |
| Image Sensor: | 1/1.8" Progressive CMOS |
| Effective Pixels: | 3840 (H) × 2160 (V) |
| RAM/Rom: | 8GB/ 2GB |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.02 lux @ F1.6 (Color) <0.005 lux @ F1.6 (B/W) 0 lux with IR illumination on |
| S/N Ratio: | 54 dB |
| Illumination Distance: | Up to 40 meters with Smart IR |
| Illumination On/Off Control: | Auto / Manual |
| Illumination LEDs: | 4x LEDs |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Motorized Vari-focal |
| Focal Length: | 4.3 ~ 9.8mm |
| Max. Aperture: | F1.6 ~ F2.6 |
| Angle of View: | Horizontal: 110.4° ~ 45.1°; Vertical: 57.9° ~ 25.4°; Diagonal: 133.9° ~ 51.8° |
| Optical Zoom: | 2.3x |
| Focus Control: | Auto / Manual |
| Close Focus Distance: | Wide: 0.3 m (1.0 ft) Tele: 0.8 m (2.6 ft) |
| DORI - Detect: | Wide: 88.1 m (289.2 ft) Tele: 197.6 m (648.2 ft) |
| DORI - Observe: | Wide: 35.0 m (114.9 ft) Tele: 77.9 m (255.7 ft) |
| DORI - Recognize: | Wide: 17.5 m (57.4 ft) Tele: 39.0 m (127.8 ft) |
| DORI - Identify: | Wide: 8.7 m (28.6 ft) Tele: 19.5 m (63.9 ft) |
| PTZ | |
| Pan/Tilt Range: | Tilt: 80 / Rotation: 350° |
| Intelligence | |
| IVS: | Line crossing; Intrusion, Unattended object; Missing object, Loitering detection, Face detection |
| Advanced Intelligent Functions: | Object Detection: People, Vehicle (4-wheeled, 2-wheeled), Human / Vehicle Best shot, Path Extraction Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color) |
| Video | |
| Compression: | H265, H264, MJPEG |
| Resolution: | 3840x2160, 3328x1872, 3072x1728, 2688x1520, 2560x1440, 1920x1080, 1280x720, 640x360 (16:9) |
| Frame Rate: | Main stream: 30 fps @ 3840x2160 (8MP) Second stream: 30fps @1920x1080 Third stream: 30 fps @ 1280x720 |
| Bit Rate Control: | Fixed Quality / Constrained |
| Bit Rate: | H.264: 20 Kbps–20 Mbps H.265: 20 Kbps–20 Mbps |
| Day/Night: | Auto(ICR) / Color / B/W / Schedule |
| Backlight Compensation: | BLC / HLC / WDR(120dB) |
| White Balance: | Default (Auto)/Fixed/Manual |
| Gain Control: | Auto / Manual |
| Noise Reduction: | 3DNR |
| Motion Detection: | Off / On (5 Area) |
| Flip: | 0°/90°/180°/270° |
| Mirror: | Off / On |
| Privacy Masking: | Off / On (5 Area) |
| WDR: | 120dB |
| Audio | |
| Compression: | G.711, G.726, MPEG-2 AAC-LC |
| Network | |
| Ethernet: | 10Base-T/100Base-TX Ethernet (RJ-45) |
| Protocol: | 802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, , NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP |
| Interoperability: | ONVIF (Profile S/Profile G/Profile T/Profile M) |
| Max. User Access: | Live streaming for up to 10 users / devices |
| Management Software: | IC Secure |
| Smart Phone: | IOS, Android |
| Interface | |
| Audio I/O: | Built-in Mic, Audio Line-in, Audio Line-out |
| Alarm I/O: | Digital Input: 1 channel Digital Output: 1 channel (DO+: 12V, 50mA; DO-: 30V, Open Drain, 1A) |
| Factory Reset: | Supported |
| Memory Slot: | Micro SD Card (support max. 1TB) |
| Electrical | |
| Power Supply: | IEEE 802.3af PoE Class 3 |
| Power Consumption: | Max. 12.4W (IR on) / 9.6W (IR off) |
| Environmental | |
| Operating Conditions: | Starting Temperature: -20°C ~ 50°C (-4°F ~ 122°F) Working Temperature: -35°C ~ 60°C (-31°F ~ 140°F) (IR off) -35°C ~ 50°C (-31°F ~ 122°F) (IR on) |
| Operating Humidity: | 98% RH (non-condensing) |
| Ingress Protection: | IP67 |
| Vandal Resistance: | IK10 |
| Construction | |
| Dimensions: | Ø 92mm x 258.5 mm (Ø 3.62" × 10.1") |
