IPEL-B80F-IRW1

(0) No Reviews yet
SKU: IPEL-B80F-IRW1
ITEM WEIGHT: 2
8MP IP Indoor/Outdoor Small Size Bullet. Fixed 2.8mm Lens (112°). 130 Feet Smart IR. PoE Capable. Ai (Advanced Intellige...
1/2.5 CMOS Starvis | 8MP | 15fps@4K
2.8mm | fixed | AoV 112
Max. IR length 131ft | Smart IR | 2 IR LEDs
128GB mSD | IVS Support
IP67 | 12VDC or PoE | E-PoE Support
IVS | AGC | 120dB True WDR | HLC | BLC | 3DNR

Details

Ultra HD Surveillance is here - now you can capture your surveillance footage in stunning 4K resolution! The new IP Elite series of 4K cameras paired with a compatible 4K series NVR will bring your surveillance system to new, unforeseen levels of clarity and resolution.

The IPEL-B80F-IRW1 is an 8MP (4K) Day/Night Bullet camera. It utilizes a cutting edge 1/2.5'' 8MP CMOS sensor deliver stunning 4K resolution at frame rates as high as 15FPS. On top of the sensor sits a fixed 4mm lens which delivers a handy, general purpose 112° Horizontal field of view. 2 high intensity IR Illuminators are equipped and yield 131' (40 meters) of IR distance, allowing long range shots as well. The camera is capable of long distance transmission with E-PoE support. This camera also represents the 'AI' line of smart cameras from ICRealtime. It's AI (Advanced Intelligence) suite of features includes: Tripwire, Intrusion, and Missing/Abandoned Objects.

Specifications

Camera
Image Sensor: 1/2.5 8 Megapixel progressive scan STARVIS CMOS
Effective Pixels: 3840(H) x 2160(V)
RAM/Rom: 512MB / 32MB
Scanning System: Progressive
Minimum Illumination: 0.06Lux/F1.6( Color1/3s30IRE) 0.3Lux/F1.6( Color1/30s30IRE) 0Lux/F1.6(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 40m (131ft)
IR On/Off Control: Auto/Manual
IR LEDs: 2
Lens
Lens Type: Fixed
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F1.6
Angle of View: H:112 degrees V:69 degrees
Focus Control: Fixed
Close Focus Distance: 900mm (35.43in)
DORI - Detect: 69m (226ft)
DORI - Observe: 28m (92ft)
DORI - Recognize: 14m (46ft)
DORI - Identify: 7m (23ft)
Intelligence
Smart Function: Tripwire / Intrusion / Abandoned or Missing Object / Face Detection
Video
Compression: H.265+ / H.265 / H.264+ / H.264
Resolution: 4K (3840 x 2160) / 6M (3072 x 2048) / 5M (2560 x 1920) / 3M (2048 x 1536) / 3M (2304 x 1296) / 1080P (1920 x 1080) / 1.3M (1280 x 960) / 720P (1280 x 720) / D1 (704 x 576 / 704 x 480) / VGA (640 x 480) / CIF (352 x 288 / 352 x 240)
Frame Rate: Main Stream: 4K(1 - 15fps) / 3M(1 - 25/30fps) Sub Stream: D1(1 - 25/30fps) Third Stream: 1080P(1 - 25/30fps)
Bit Rate: H.264: 24K - 10240Kbps H.265: 14K - 9984Kbps
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / WDR(120dB)
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual
Gain Control: Auto / Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zones Rectangular)
Region of Interest: Off / On (4 Zones)
Smart IR: Supported
Digital Zoom: 16x
Flip: 0 / 90 / 180 / 270 (90/ 270 only supported at 4MP or less)
Mirror: Off / On
Privacy Masking: Up to 4 areas
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP / HTTPs / TCP / ARP / RTSP / RTP / UDP / SMTP / FTP / DHCP / DNS / DDNS / PPPOE / IPv4 / IPv6 / QoS / UPnP / NTP / Bonjour / 802.1x / Multicast / ICMP / IGMP / SNMP
Interoperability: ONVIF / PSIA / CGI
Compatability: ONVIF / PSIA / CGI
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users
Edge Storage: NAS / Local PC for instant recording / Micro SD Card 128GB
Interface
Video Interface: N/A
Memory Slot: Micro SD Card 128GB
Electrical
Power Supply: DC12V PoE (802.3af)(Class 0)
E-PoE Support
Power Consumption: < 6.5W
Enviromental
Operating Conditions: -30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH
Ingress Protection: IP67
Construction
Casing: Metal
Dimensions: 180mm x 70mm x 70mm (7.09in x 2.76in x 2.76in)
Gross Weight: 0.53 kg (1.17lb)
Mounting Pan/Tilt/Rotation: Pan:0 ~ 360 ; / Tilt:0 ~ 90 ; / Rotation:0 ~ 360
