ICIP-MLD42-IR

(0) No Reviews yet
SKU: ICIP-MLD42-IR
ITEM WEIGHT: 10
4 x 2MP Multi Lens IP Dome I-Sniper 4 x 2.7 - 12 mm Motorized Lens (105 AOV) 98 ft of IR POE+ Capable
Four 1/2.8 CMOS Starvis | 2MP | 30fps@2MP
2.7mm to 12mm | motorized varifocal | H:105-44° V:54-25
Max. IR LEDs Length 98Ft (30m) | 8 IR LEDs
1ch audio in 1ch audio out | 1ch alarm in 1ch alarm out | 256GB mSD
IP67 | 24VAC or PoE+ | Max. 31.2W
IVS | AGC | 140dB WDR | HLC | BLC | 3DNR

On Back Order

Details

It's no secret that there's a need for wide coverage options ranging from 180-degree to 360-degree angles. IC Realtime debuts their new multi-sensor camera which will address affordability, quality, and situational coverage - all in a tidy package. The flexibility to capture wide area footage is immense - and with 4 adjustable 2MP lenses, the camera replaces multiple single sensor cameras. It is also noteworthy that the unit requires only one cable run, giving installers greater flexibility in terms of wiring. The unit is ideal for monitoring wide open spaces, building corners, parking lots and intersecting hallways. A beneficial feature available is IR synchronicity - which adjusts in sync with the position of each sensor. With this level of control, dealers can expect to produce clear imagery in total darkness - regardless of the position of the sensor on the track. The device also features Starlight Technology which keeps the camera in color when low light performance and usable video with minimal ambient light is required. This unit will produce vivid pictures even in the most intense contrast condition thanks to True Wide Dynamic Range (140dB). This allows for optimization to provide exceptional footage in applications where both bright and low light conditions exist or change quickly. The combination of such features allows for easy & accurate identification from within a typical field of view. Built with intelligence in mind, the unit is capable of detecting and analyzing moving objects for improved surveillance and virtually eliminates false alerts. In terms of flexibility, users will be delighted to learn that the unit supports H.265 encoding and equipped with (4) 2.7mm ~ 12mm motorized lenses. The unit may be powered with either 24 volts AC or PoE+.

Specifications

Camera
Image Sensor: Four 1/2.8” 2 Megapixel progressive scan CMOS
Effective Pixels: 1920(H)x1080(V)
RAM/Rom: 1024MB/128MB
Scanning System: Progressive
Electronic Shutter Speed: N/A
Minimum Illumination: 0.005Lux/F1.8( Color,1/3s,30IRE) 0.06Lux/1.8( Color,1/30s,30IRE) 0Lux/F1.8(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 30m (98ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 8
Lens
Lens Type: Motorized
Mount Type: Board-in
Focal Length: 2.7~12mm motorized
Max. Aperture: F1.8
Angle of View: H: 105° ~44°, V:54° ~25°
Optical Zoom: 4x
Focus Control: Motorized
Close Focus Distance: 0.2m(0.66ft)
DORI - Detect: 45m(148ft) - 99m(325ft)
DORI - Observe: 18m(59ft) - 40m(131ft)
DORI - Recognize: 9m(29.5ft) - 20m(66ft)
DORI - Identify: 4.5m(14.8ft) - 10m(33ft)
Video
Compression: H.265/H.264/H.264B/H.264H/MJPEG(sub stream)
Resolution: 1080P(1920×1080)/1.3M(1280x960)/ 720P(1280x720)/D1(704×576/704x480)/ CIF(352×288/352×240)
Frame Rate: Main Stream: 1080P(1~25/30fps)<br />Sub Stream: D1(1~25/30fps)
Bit Rate: H.264: 32~8192Kbps H.265: 12~6144Kbps
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / WDR(140dB)
White Balance: Auto/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS): N/A
Smart IR: N/A
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)
Audio
Compression: G.711a/ G.711Mu/ AAC/ G.726
Network
Ethernet: RJ-45 (100/1000Base-T)
Protocol: HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP
Interoperability: ONVIF Profile S&G, API
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users /20 Users
Edge Storage: NAS
Local PC for instant recording
Micro SD card 256GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart ICRSS, ICRSS Pro
Smart Phone: IOS, Android
Interface
Video Interface: N/A
RS485: 1 port
Audio I/O: 1/1 channel In/Out
Alarm I/O: 1 channel In: 5mA 5VDC 1 channel Out: 300mA 12V
Memory Slot: 256GB
Electrical
Power Supply: AC24V, PoE+(802.3at)(Class 4)
Power Consumption: AC 24V: 9.9W 31.2W(IR on) PoE: 10.6W 23.8W(IR on)
Enviromental
Operating Conditions: -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: IK10
Construction
Casing: Metal
Dimensions: 286.1mm×111.3mm
Gross Weight: 3.6kg (7.94lb)
