HD2-B30
Details
The HD2-B30 is a 1080p HD-AVS/CVBS Dual output sealed bullet style camera. It has a 2MP 3.6mm lens and IR distance up to 164 feet with Smart IR support. It is also IP67 weatherproof rated.
Specifications
| Camera | |
| Image Sensor: | 1/2.8" 2.4Megapixel CMOS |
| Effective Pixels: | 1984(H)×1225(V) |
| Minimum Illumination: | 0.05Lux@F1.2(AGC ON), 0Lux IR on |
| Illumination Distance: | 50m (164 feet) |
| Illumination LEDs: | Yes |
| IR Wavelength: | 850 nm |
| Camera Illumination Type: | IR |
| Lens | |
| Mount Type: | M12 |
| Focal Length: | 3.6mm |
| Angle of View: | H: 53.4º(88º/39º) |
| PTZ | |
| OSD Menu: | Support |
| Video | |
| Resolution: | 1080P, 720P, CVBS |
| Frame Rate: | 25/30/50/60fps@720P; 25/30fps@1080P |
| Day/Night: | Auto(ICR) / Color / B/W |
| Backlight Compensation: | Support |
| White Balance: | Support |
| Gain Control: | Support |
| Noise Reduction: | Support |
| Smart IR: | Support |
| WDR: | Support |
| Interface | |
| Video Interface: | 1-channel BNC HD AVS high definition video output / CVBS standard definition video output (Can switch) |
| Electrical | |
| Power Supply: | DC12V±10% |
| Power Consumption: | Max 6W |
| Environmental | |
| Operating Conditions: | -30°C~+60°C / Less than 95%RH (no condensation) |
| Ingress Protection: | IP67 |
| Construction | |
| Casing: | Metal (front) + Plastic (body) |
