AVS-B8712SL-DP
Details
Experience 4K video surveillance with the simplicity of reusing existing coaxial infrastructure! The AVS-B8712SL-DP camera adopts a powerful 1/1.8'' imager as well as a varifocal 3.7-11mm motorized zoom lens, providing superior quality imaging. It also supports Starlight technology and 120dB true WDR for a clear image in even poor lighting conditions. In addition, this camera supports an Audio Input for an external microphone to capture broadcast quality audio and improve supplementary evidence collection. IR illumination reaches 262' at 0 lux. Ultra high definition and a complete set of features makes this 4K HD-AVS camera an ideal choice for mid to large-size businesses and projects where both highly reliable surveillance and construction flexibility are demanded.
Note:For compatibility purposes, this camera may come default on 4MP/ 2MP resolution. When equipped with an appropriate HDVR, you can set the camera to the maximum resolution via the OSD interface.
Note:For compatibility purposes, this camera may come default on 4MP/ 2MP resolution. When equipped with an appropriate HDVR, you can set the camera to the maximum resolution via the OSD interface.
Specifications
| Camera | |
| Image Sensor: | 1/1.8" Starlight CMOS |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.005Lux/F1.5 30IRE 0Lux IR on |
| S/N Ratio: | More than 65dB |
| Illumination Distance: | Up to 80m (262ft) |
| Illumination On/Off Control: | Auto / Manual |
| Illumination LEDs: | 4 |
| IR Wavelength: | 850 nm |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Motorized lens / Fixed iris |
| Mount Type: | Board-in |
| Focal Length: | 3.7-11mm |
| Max. Aperture: | F1.5 |
| Angle of View: | H: 112 - 46 degrees |
| Focus Control: | Auto/Manual |
| Close Focus Distance: | 200mm (7.87in) |
| DORI - Detect: | 83m (272ft) / 190m (623ft) |
| DORI - Observe: | 33m (108ft) / 76m (249ft) |
| DORI - Recognize: | 17m (56ft) / 38m (125ft) |
| DORI - Identify: | 8m (26ft) / 19m (62ft) |
| PTZ | |
| Pan/Tilt Range: | Pan: 0 ~ 360 / Tilt: 0 ~ 90 / Rotation: 0 ~ 360 |
| OSD Menu: | Multi-language |
| Video | |
| Resolution: | 8MP (3840 x 2160) |
| Frame Rate: | 15fps@4K 20fps@6MP 25/30fps@4MP |
| Day/Night: | Auto (ICR) / Manual |
| Backlight Compensation: | BLC / HLC / WDR |
| White Balance: | Auto / Manual |
| Gain Control: | AGC |
| Noise Reduction: | 2D / 3D |
| Smart IR: | Auto / Manual |
| WDR: | 120dB |
| Interface | |
| Video Interface: | 1-channel BNC high definition video output / CVBS video output (DIP switch) |
| Audio I/O: | 1-channel audio in & Built-in Mic |
| Electrical | |
| Power Supply: | AC 24V +/- 30% / DC 12V +/- 30% |
| Power Consumption: | Max 15W (12V DC IR on) |
| Environmental | |
| Operating Conditions: | -30C ~ +60C (-22F ~ +140F) / Less than 90% RH |
| Ingress Protection: | IP67 |
| Construction | |
| Casing: | Aluminium |
| Dimensions: | 244.1mm x 90.4mm x 90.4mm (9.61in x 3.56in x 3.56in) |
| Gross Weight: | 1.05kg (2.31lb) |
