AVS-5MD4021-IR-M

(0) No Reviews yet
SKU: AVS-5MD4021-IR-M
ITEM WEIGHT: 2
5MP HD-AVS Indoor/Outdoor Mid Size Eyeball Dome Fixed 2.8mm Lens (98 AOV) 164 ft Smart IR Built-in Mic 12VDC
1/2.8" CMOS | 5MP | 20fps@5MP
2.8mm | fixed | AoV 98
Max. IR length 164ft | Smart IR | 2 IR LEDs
1ch audio in | built-in mic
IP67 | 12VDC | Max. 7W
AGC | 120dB WDR | HLC | BLC | 3DNR

Details

"Experience 5 megapixel video with the simplicity of reusing existing coaxial infrastructure! The AVS-5MD4021-IR camera utilizes starlight and HD-AVS technology, suitable to produce a high quality image with rich details even under extreme low-light conditions. The camera also features built in mic capable to provide enhanced supplementary evidence collection. It utilizes a fixed 2.8mm lens and an imager capable of 120dB true WDR and a switchable HD/SD output. IR illumination is available thanks to intelligent IR LEDs capable of illumination at 0 lux up to 164'. Both the high resolution as well as the starlight sensor feature makes this HD-AVS camera an ideal choice for mid to large-size business and projects where both highly reliable surveillance and construction flexibility are needed. "

Specifications

Camera
Image Sensor: 1/2.8" CMOS
Effective Pixels: 2592(H)×1944(V), 5MP
Scanning System: Progressive
Minimum Illumination: 0.005Lux/F1.6, 30IRE, 0Lux IR on
S/N Ratio: More than 65dB
IR Distance: Up to 50m (164feet)
IR On/Off Control: Auto / Manual
IR LEDs: 2
Lens
Lens Type: Fixed lens / Fixed iris
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F1.6
Angle of View: H: 98°
Focus Control: Auto / Manual
Close Focus Distance: 1300mm (800mm, 3000mm)
51.2'' (31.5", 118")
DORI - Detect: 56m(184ft)
DORI - Observe: 22m(72ft)
DORI - Recognize: 11m(36ft)
DORI - Identify: 6m(20ft)
PTZ
OSD Menu: Multi-language
Video
Resolution: 5MP (2592×1944)
Frame Rate: 20fps@5MP, 25/30fps@4MP, 25/30fps@1080P
Day/Night: Auto (ICR) / Manual
Backlight Compensation: BLC / HLC / WDR
White Balance: Auto / Manual
Gain Control: AGC
Noise Reduction: 2D/3D
Smart IR: Auto / Manual
WDR: 120dB
Interface
Video Interface: 1-channel BNC high definition video output / CVBS video output (DIP switch)
Audio I/O: 1ch in & Built-in Mic
Electrical
Power Supply: 12V DC ±30%
Power Consumption: Max. 7W (12V DC, IR on)
Enviromental
Operating Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

* Start up should be done at above -40°C (-40°F)
Ingress Protection: IP67
Construction
Casing: Aluminium
Dimensions: Φ106mm×99.2mm (Φ4.17"×3.9")
Gross Weight: 0.63kg (1.39lb)
