AVS-5MB4012-IR-M

(0) No Reviews yet
SKU: AVS-5MB4012-IR-M
ITEM WEIGHT: 3
5MP HD-AVS Indoor/Outdoor Mid Size Bullet Fixed 2.8mm Lens (79 AOV) 130 ft Smart IR 12VDC Built-in MIC
1/2.8" CMOS | 5MP | 20fps@5MP
2.8mm | fixed | AoV 98
Max. IR length 130ft | Smart IR | 2 IR LEDs
1ch audio in | built-in mic
IP67 | 12VDC | Max. 7W
AGC | 120dB WDR | HLC | BLC | 3DNR

Details

Experience 5 megapixel video with the simplicity of reusing existing coaxial infrastructure! The AVS-5MB4012-IR camera utilizes starlight and HD-AVS technology, suitable to produce a high quality image with rich details even under extreme low-light conditions. The camera also features broadcast quality audio to provide enhanced supplementary evidence collection. It utilizes a fixed 2.8mm lens and an imager capable of 120dB true WDR and a switchable HD/SD output. Both the high resolution as well as the starlight sensor feature makes this HD-AVS camera an ideal choice for mid to large-size business and projects where both highly reliable surveillance and construction flexibility are needed.

Specifications

Camera
Image Sensor: 1/2.8 Starlight CMOS
Effective Pixels: 2592(H) x 1944(V)
Scanning System: Progressive
Minimum Illumination: 0.005Lux/F1.6 30IRE 0Lux IR on
S/N Ratio: More than 65dB
IR Distance: Up to 40m (130ft)
IR On/Off Control: Auto / Manual
IR LEDs: 2
Lens
Lens Type: Fixed lens / Fixed iris
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F1.6
Angle of View: H: 98 degrees
Focus Control: N/A
Close Focus Distance: 800mm (31.5in)
DORI - Detect: 56m (184ft)
DORI - Observe: 22m (72ft)
DORI - Recognize: 11m (36ft)
DORI - Identify: 6m (20ft)
PTZ
Pan/Tilt Range: Pan: 0 ~ 360 / Tilt: 0 ~ 90 / Rotation: 0 ~ 360
OSD Menu: Multi-language
Video
Resolution: 5MP (2592 x 1944)
Frame Rate: 20fps@5MP 25/30fps@4MP 25/30fps@1080P
Day/Night: Auto (ICR) / Manual
Backlight Compensation: BLC / HLC / WDR
White Balance: Auto / Manual
Gain Control: AGC
Noise Reduction: 2D / 3D
Smart IR: Auto / Manual
WDR: 120dB
Interface
Video Interface: 1-channel BNC high definition video output / CVBS video output (DIP switch)
Audio I/O: 1-channel audio in & Built-in Mic
Electrical
Power Supply: 12V DC +/- 30%
Power Consumption: Max. 7W (12V DC IR on)
Enviromental
Operating Conditions: -40C ~ +60C (-40F ~ +140F) / Less than 90% RH
Ingress Protection: IP67
Construction
Casing: Aluminium
Dimensions: 179.9mm x 70mm x 70mm (7.08in x 2.76in x 2.76in)
Gross Weight: 0.53kg (1.17lb)
