AVS-5MB4010-IR-M

(0) No Reviews yet
SKU: AVS-5MB4010-IR-M
ITEM WEIGHT: 3
5MP HD-AVS Indoor/Outdoor Mid Size Bullet Fixed 3.6mm Lens (79 AOV) 262 ft Smart IR 12VDC Built-in MIC
1/2.8" CMOS | 5MP | 20fps@5MP
3.6mm | fixed | AoV 79
Max. IR length 262ft | Smart IR | 4 IR LEDs
1ch audio in | built-in mic
IP67 | 12VDC | Max. 10W
AGC | 120dB WDR | HLC | BLC | 3DNR

Details

Experience 5 megapixel video with the simplicity of reusing existing coaxial infrastructure! The AVS-5MB4010-IR-M camera utilizes starlight and HD-AVS technology, suitable to produce a high quality image with rich details even under extreme low-light conditions. The camera also features broadcast quality audio to provide enhanced supplementary evidence collection. It utilizes a fixed 3.6mm lens and an imager capable of 120dB true WDR and a switchable HD/SD output. IR illumination on this model camera reaches 262 feet at 0 lux. Both the high resolution as well as the starlight sensor feature makes this HD-AVS camera an ideal choice for mid to large-size business and projects where both highly reliable surveillance and construction flexibility are needed.

Specifications

Camera
Image Sensor: 1/2.8" CMOS
Effective Pixels: 2592(H)x1944(V), 5MP
Scanning System: Progressive
Minimum Illumination: 0.005Lux/F1.6, 30IRE, 0Lux IR on
S/N Ratio: More than 65dB
IR Distance: Up to 80m (262ft)
IR On/Off Control: Auto / Manual
IR LEDs: 4
Lens
Lens Type: Fixed lens / Fixed iris
Focal Length: 3.6mm
Max. Aperture: F1.6
Angle of View: H: 79°
Focus Control: Fixed
Close Focus Distance: 1300mm(51.2ft)
DORI - Detect: 72m(236ft)
DORI - Observe: 29m(95ft)
DORI - Recognize: 14m(46ft)
DORI - Identify: 7m(23ft)
PTZ
OSD Menu: Multi-language
Video
Resolution: 5MP (2592×1944)
Frame Rate: 20fps@5MP, 25/30fps@4MP, 25/30fps@1080P
Day/Night: Auto (ICR) / Manual
Backlight Compensation: BLC / HLC / WDR
White Balance: Auto / Manual
Gain Control: AGC
Noise Reduction: 2D/3D
Smart IR: Auto / Manual
WDR: 120dB
Interface
Video Interface: 1-channel BNC high definition video output / CVBS video
output (DIP switch)
RS485: N/A
Alarm I/O: N/A
Electrical
Power Supply: 12V DC ±30%
Power Consumption: Max. 10W (12V DC, IR on)
Enviromental
Operating Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
*Start up should be done at above -40°C (-40°F)
Storage Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
Ingress Protection: IP67
Construction
Casing: Aluminum
Dimensions: 228.6mm×70mm×70mm (9"×2.76"×2.76")
Gross Weight: 0.53kg (1.17lb)
Mounting Pan/Tilt/Rotation: Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotation: 0° ~ 360°
