AVR-1708

(0) No Reviews yet
SKU: AVR-1708-WEB
ITEM WEIGHT: 10
8 Channel 1U Pentabrid DVR - Supports up to 8MP Resolution - H.265 - HDMI
8+8 Ch | Up to 8MP | 64Mbps Total
2 HDDs
1 RJ-45 (10/100/1000Mbps)
2 USB | Alarm 8/3 | 1 HDMI / 1 VGA
ONVIF 16.12 CGI Conformant
1U | Desktop or Rack Shelf

Details

The AVR-1700 series recorder - the best of all three worlds: analog, AVS, and IP. Ideal for installations where the environment is mixed between analog and IP Cameras, or for upgrading existing systems to the next level of resolution. The AVR-1700 series recorders are capable of recording analog cameras at 960H resolution, HDAVS cameras and IP cameras up to 1080P. Audio is supported on each and every input (both analog, and IP). The AVR-1700 series recorders are wrapped up in a 1U DVR capable of housing 2 HDDs internally. AVR-1700 series recorders are available in 4, 8, and 16 channel offerings, enabling it to be deployed into diverse, and varying sized installations ranging from small office, to large scale enterprises applications. Since the Hybrid series of recorders supports both analog, HDAVS, and IP cameras, it is a good fit for existing installations that want to expand into IP cameras, without replacing analog cameras. Like all IC Realtime series recorders, this device utilizes H.264E (Enhanced H.264) compression technology, enabling crisp image viewing with the least bandwidth consumption possible. This unit adopts an embedded system design, as well as a Linux Operating System, resulting in high levels of stability, performance, and most importantly: reliability. In addition, this unit is fully operational from remote locations (Search / Playback / Backup / Configuration) over standard Ethernet networks.

Specifications

System
Main Processor: Embedded Processor
Operating System: Embedded LINUX
Display
Display Interface: 1 HDMI, 1 VGA
Display Resolution: HDMI:3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720 VGA: 1920 x 1080, 1280 x 1024, 1280 x 720
Multi-screen Display: When IP extension mode not enabled: 1/4/8/9, When IP extension mode enabled: 1/4/8/9/16
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video
IP Camera Input: 8+8 Channel, each channel up to 8MP
HDAVS input: 8 Channel, BNC (HD-AVS Camera 4K, 6MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps, AHD Camera 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps, TVI Camera5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps, CVBS Camera PAL/NTSC)
Trigger Events: Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 x 18), Video Loss,Tampering and Diagnosis
Playback: 1 / 4 / 9
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Bit Rate: 32Kbps ~ 6144Kbps Per Channel
Audio
Compression: AAC(only for the 1st channel), G.711A, G.711U, PCM
Two-way Talk: Reuse audio in/out, RCA
Recording
Record Compression: H.265+/H.265/H.264+/H.264
Record Resolution: 4K, 6MP, 5MP, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF
Record Rate: Main stream: 4K(1~7fps); 6MP(1~10fps); 5MP(1~12fps); 4MP/3MP(1~15fps); 4M-N/1080P/720P/960H/D1/CIF(1~25/30fps) Sub stream:960H(1~15fps); D1/CIF(1~25/30fps)
Record Mode: Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval: 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Storage
Internal HDD: 2 SATA Ports, up to 10TB capacity for each disk
Network
Ethernet: 1 RJ-45 Port (1000M)
Protocol: HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search
Compatability: IC Realtime, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Max. User Access: 128 Users
Smart Phone: iPhone, iPad, Android
Interface
RS232: N/A
RS485: 1 Port, for PTZ Control
USB: 2 USB Ports (1 USB 2.0 , 1 USB 3.0)
Electrical
Power Supply: DC12V/4A
Power Consumption: <10W
Enviromental
Operating Conditions: -10C ~ +55C (+14F ~ +131F), 10% ~ 90% RH
Storage Conditions: -20C ~ +70C (-4F ~ +158F) , 0~ 90% RH
Construction
Installation: Desktop installation
Dimensions: 1U, 375mm x 287mm x 53mm (14.8" x 11.3" x 2.1")
